In this tutorial, we explore adaptive experimentation using Meta’s Ax with the modern Client API. We work through a complete workflow where we tune a RandomForest model on a synthetic classification dataset while balancing predictive accuracy against model footprint. We begin by defining a mixed search space with integer, float, log-scaled, and categorical parameters, then use Ax’s ask-tell optimization loop to run constrained Bayesian optimization, multi-objective optimization, and parameter-constrained experimentation. Along the way, we visualize convergence, inspect the Pareto frontier, use Ax’s built-in analysis tools, and persist the experiment for future reuse. Copy CodeCopiedUse a different Browser import importlib, subprocess, sys def _ensure(module, pip_name=None): try: importlib.import_module(module) except ImportError: print(f”Installing {pip_name or module} …”) subprocess.check_call([sys.executable, “-m”, “pip”, “install”, “-q”, pip_name or module]) _ensure(“ax”, “ax-platform”) _ensure(“sklearn”, “scikit-learn”) import logging, warnings, time import numpy as np import matplotlib.pyplot as plt warnings.filterwarnings(“ignore”) logging.getLogger(“ax”).setLevel(logging.WARNING) from ax.api.client import Client from ax.api.configs import RangeParameterConfig, ChoiceParameterConfig from sklearn.datasets import make_classification from sklearn.ensemble import RandomForestClassifier from sklearn.model_selection import StratifiedKFold, cross_val_score np.random.seed(0) We begin by preparing the Colab environment and installing the required packages for Ax and scikit-learn. We import the core libraries for optimization, machine learning, plotting, logging, and reproducibility. We also configure warnings and Ax logging to keep the notebook output clean and focused on the experimental results. Copy CodeCopiedUse a different Browser X, y = make_classification( n_samples=1400, n_features=20, n_informative=8, n_redundant=4, n_classes=3, random_state=0, ) CV = StratifiedKFold(n_splits=3, shuffle=True, random_state=0) def evaluate(p): n_est, depth = int(p[“n_estimators”]), int(p[“max_depth”]) clf = RandomForestClassifier( n_estimators=n_est, max_depth=depth, max_features=float(p[“max_features”]), min_samples_leaf=int(p[“min_samples_leaf”]), criterion=p[“criterion”], ccp_alpha=float(p[“ccp_alpha”]), n_jobs=-1, random_state=0, ) accuracy = cross_val_score(clf, X, y, cv=CV, scoring=”accuracy”).mean() model_size = n_est * depth return {“accuracy”: float(accuracy), “model_size”: float(model_size)} SEARCH_SPACE = [ RangeParameterConfig(name=”n_estimators”, bounds=(50, 300), parameter_type=”int”), RangeParameterConfig(name=”max_depth”, bounds=(3, 24), parameter_type=”int”), RangeParameterConfig(name=”max_features”, bounds=(0.2, 1.0), parameter_type=”float”), RangeParameterConfig(name=”min_samples_leaf”,bounds=(1, 12), parameter_type=”int”), RangeParameterConfig(name=”ccp_alpha”, bounds=(1e-5, 1e-1), parameter_type=”float”, scaling=”log”), ChoiceParameterConfig(name=”criterion”, values=[“gini”, “entropy”, “log_loss”], parameter_type=”str”, is_ordered=False), ] def run_study(client, total_trials, metric_keys, batch=4): records = [] while len(records) < total_trials: trials = client.get_next_trials(max_trials=min(batch, total_trials – len(records))) if not trials: break for idx, params in trials.items(): full = evaluate(params) raw = {k: full[k] for k in metric_keys} client.complete_trial(trial_index=idx, raw_data=raw) records.append({“trial”: idx, “params”: params, **full}) return records We create a synthetic multi-class classification dataset and define a cross-validation strategy to evaluate Random Forest models. We build an evaluation function that returns both accuracy and model size, allowing us to measure performance and cost together. We then define a mixed search space with integer, float, log-scaled, and categorical parameters, along with a reusable ask-tell study runner. Copy CodeCopiedUse a different Browser print(“n=== Study 1: constrained single-objective Bayesian optimization ===”) c1 = Client() c1.configure_experiment(parameters=SEARCH_SPACE, name=”rf_constrained”) c1.configure_optimization(objective=”accuracy”, outcome_constraints=[“model_size <= 2500”]) rec1 = run_study(c1, total_trials=24, metric_keys=[“accuracy”, “model_size”]) best_params, prediction, best_idx, best_arm = c1.get_best_parameterization() print(“nBest feasible configuration found:”) for k, v in best_params.items(): print(f” {k:>16}: {v}”) print(” predicted:”, prediction) feasible = [(r[“trial”], r[“accuracy”]) for r in rec1 if r[“model_size”] <= 2500] best_so_far, cur = [], -np.inf for _, acc in feasible: cur = max(cur, acc); best_so_far.append(cur) plt.figure(figsize=(7, 4)) plt.plot(range(1, len(best_so_far) + 1), best_so_far, “o-“) plt.xlabel(“feasible trial #”); plt.ylabel(“best accuracy so far”) plt.title(“Study 1 — convergence (subject to model_size <= 2500)”) plt.grid(alpha=0.3); plt.tight_layout(); plt.show() We run a constrained single-objective Bayesian optimization study where we maximize accuracy while keeping model size below a fixed threshold. We use Ax to suggest hyperparameter configurations, evaluate them, and report both accuracy and model size back to the optimizer. We then extract the best feasible configuration and plot the best accuracy achieved over feasible trials. Copy CodeCopiedUse a different Browser print(“n=== Study 2: multi-objective (accuracy vs. model_size) ===”) c2 = Client() c2.configure_experiment(parameters=SEARCH_SPACE, name=”rf_multiobjective”) c2.configure_optimization(objective=”accuracy, -model_size”) rec2 = run_study(c2, total_trials=28, metric_keys=[“accuracy”, “model_size”]) try: frontier = c2.get_pareto_frontier() print(f”Ax identified {len(frontier)} Pareto-optimal configurations.”) except Exception as e: frontier = None print(“get_pareto_frontier unavailable in this version:”, e) acc = np.array([r[“accuracy”] for r in rec2]) size = np.array([r[“model_size”] for r in rec2]) order = np.argsort(size) pareto_idx, best_acc = [], -np.inf for i in order: if acc[i] > best_acc: best_acc = acc[i]; pareto_idx.append(i) plt.figure(figsize=(7, 5)) plt.scatter(size, acc, c=”lightgray”, label=”all trials”) plt.scatter(size[pareto_idx], acc[pareto_idx], c=”crimson”, zorder=3, label=”Pareto front”) plt.plot(size[pareto_idx], acc[pareto_idx], “–“, c=”crimson”, alpha=0.6) plt.xlabel(“model_size (lower = cheaper)”); plt.ylabel(“accuracy (higher = better)”) plt.title(“Study 2 — accuracy vs. model size trade-off”) plt.legend(); plt.grid(alpha=0.3); plt.tight_layout(); plt.show() We move from single-objective optimization to multi-objective optimization by jointly maximizing accuracy and minimizing model size. We use Ax to search for configurations that represent strong trade-offs between predictive performance and computational footprint. We then calculate and visualize the empirical Pareto frontier to understand how accuracy varies with model size. Copy CodeCopiedUse a different Browser print(“n=== Study 3: parameter constraints on a synthetic surface ===”) c3 = Client() c3.configure_experiment( parameters=[ RangeParameterConfig(name=”x1″, bounds=(0.0, 1.0), parameter_type=”float”), RangeParameterConfig(name=”x2″, bounds=(0.0, 1.0), parameter_type=”float”), ], parameter_constraints=[“x1 + x2 <= 1.5″], name=”constrained_surface”, ) c3.configure_optimization(objective=”-dist”) for _ in range(14): for idx, p in c3.get_next_trials(max_trials=1).items(): dist = (p[“x1”] – 0.9) ** 2 + (p[“x2”] – 0.9) ** 2 c3.complete_trial(trial_index=idx, raw_data={“dist”: float(dist)}) bp, _, _, _ = c3.get_best_parameterization() print(f”Best point: x1={bp[‘x1’]:.3f}, x2={bp[‘x2’]:.3f}, ” f”sum={bp[‘x1’] + bp[‘x2’]:.3f} (constraint: <= 1.5)”) print(“Unconstrained optimum would be (0.9, 0.9); Ax respects the boundary.”) We demonstrate parameter constraints using a simple two-dimensional synthetic optimization problem. We ask Ax to minimize the distance to a target point while enforcing the input constraint that the sum of the two variables remains below a boundary. We observe that the optimizer respects the constraint and finds the best feasible point near the constrained optimum. Copy CodeCopiedUse a different Browser print(“n=== Ax built-in analyses for Study 1 ===”) try: import plotly.io as pio if “google.colab” in sys.modules: pio.renderers.default = “colab” cards = c1.compute_analyses(display=True) print(f”Computed {len(cards)} analysis cards.”) except Exception as e: print(“Interactive analyses didn’t render in this environment:”, e) print(“(The matplotlib plots above already capture the key results.)”) print(“n=== Saving / loading the experiment ===”) try: c1.save_to_json_file(“ax_study1.json”) reloaded = Client.load_from_json_file(“ax_study1.json”) print(“Saved to ax_study1.json and reloaded successfully.”) rp, _, _, _ = reloaded.get_best_parameterization() print(“Best params from reloaded client match:”, rp == best_params) except Exception as e: print(“JSON persistence API differs in this version:”, e) print(“See: https://ax.dev/docs/recipes/experiment-to-json”) print(“nDone. You optimized a mixed-type search space with constraints, ” “traced a Pareto frontier, and persisted in the experiment.”) We use Ax’s built-in
