In this tutorial, we explore FAIRChem v2 and the UMA universal machine-learning interatomic potential as a unified framework for atomistic simulation across molecular chemistry, catalysis, and inorganic materials. We configure an environment, authenticate with Hugging Face to access the gated UMA model weights, and initialize task-specific calculators for the omol, oc20, and omat domains. We then apply the same pretrained potential to a broad set of computational chemistry workflows, including single-point energy and force prediction, molecular geometry optimization, spin-state comparison, reaction-energy estimation, vibrational analysis, surface adsorption, crystal-cell relaxation, equation-of-state fitting, molecular dynamics, and potential-energy surface scanning. Throughout the tutorial, we integrate FAIRChem with the Atomic Simulation Environment to manage atomic structures, optimizers, constraints, thermodynamic calculations, and trajectory analysis while using GPU acceleration whenever it is available. Copy CodeCopiedUse a different Browser import importlib.util, subprocess, sys, os def _pip(*pkgs): subprocess.check_call([sys.executable, “-m”, “pip”, “install”, “-q”, *pkgs]) if importlib.util.find_spec(“fairchem”) is None: print(“>> Installing fairchem-core, ase, and helpers (takes ~2-4 min)…”) _pip(“fairchem-core”, “ase”, “matplotlib”, “huggingface_hub”) print(“>> Installation done.”) else: print(“>> fairchem already installed.”) from huggingface_hub import login, whoami def hf_authenticate(): token = None try: from google.colab import userdata token = userdata.get(“HF_TOKEN”) except Exception: pass token = token or os.environ.get(“HF_TOKEN”) try: whoami() print(“>> Already authenticated with Hugging Face.”) return except Exception: pass if token is None: from getpass import getpass token = getpass(“Paste your Hugging Face access token: “).strip() login(token=token) print(“>> Hugging Face login OK.”) hf_authenticate() import numpy as np import torch import matplotlib.pyplot as plt from fairchem.core import pretrained_mlip, FAIRChemCalculator DEVICE = “cuda” if torch.cuda.is_available() else “cpu” print(f”>> Using device: {DEVICE}”) MODEL = “uma-s-1p2″ predictor = pretrained_mlip.get_predict_unit(MODEL, device=DEVICE) calc_mol = FAIRChemCalculator(predictor, task_name=”omol”) calc_cat = FAIRChemCalculator(predictor, task_name=”oc20″) calc_mat = FAIRChemCalculator(predictor, task_name=”omat”) print(f”>> Loaded {MODEL} with omol / oc20 / omat calculators.”) We install the required FAIRChem, ASE, visualization, and Hugging Face dependencies while ensuring the setup remains safe to rerun in Google Colab. We authenticate with Hugging Face to access the gated UMA model weights and automatically detect whether GPU acceleration is available. We then load the UMA predictor and create separate calculators for molecular, catalysis, and materials simulations. Copy CodeCopiedUse a different Browser from ase.build import molecule from ase import Atoms print(“n” + “=”*70) print(“SECTION 2: Single-point energetics of water (omol task)”) print(“=”*70) h2o = molecule(“H2O”) h2o.info.update({“charge”: 0, “spin”: 1}) h2o.calc = calc_mol E_h2o = h2o.get_potential_energy() F_h2o = h2o.get_forces() print(f”E(H2O) = {E_h2o:.4f} eV”) print(f”Max |force| = {np.abs(F_h2o).max():.4f} eV/A”) def atom_energy(symbol, spin): a = Atoms(symbol, positions=[[0, 0, 0]]) a.info.update({“charge”: 0, “spin”: spin}) a.calc = calc_mol return a.get_potential_energy() E_O = atom_energy(“O”, spin=3) E_H = atom_energy(“H”, spin=2) E_atomization = -(E_h2o – E_O – 2 * E_H) print(f”Atomization energy of H2O = {E_atomization:.3f} eV ” f”(experiment ~ 9.5 eV incl. ZPE effects)”) from ase.optimize import LBFGS print(“n” + “=”*70) print(“SECTION 3: Relaxing a deliberately distorted water molecule”) print(“=”*70) h2o_bad = molecule(“H2O”) h2o_bad.positions[1] += [0.25, -0.10, 0.05] h2o_bad.info.update({“charge”: 0, “spin”: 1}) h2o_bad.calc = calc_mol opt = LBFGS(h2o_bad, logfile=None) energies_opt = [] opt.attach(lambda: energies_opt.append(h2o_bad.get_potential_energy())) opt.run(fmax=0.01, steps=200) d_OH = h2o_bad.get_distance(0, 1) ang = h2o_bad.get_angle(1, 0, 2) print(f”Converged in {opt.get_number_of_steps()} steps”) print(f”O-H bond length = {d_OH:.3f} A (expt ~0.958 A)”) print(f”H-O-H angle = {ang:.1f} deg (expt ~104.5 deg)”) plt.figure(figsize=(5, 3.2)) plt.plot(energies_opt, “o-“) plt.xlabel(“Optimizer step”); plt.ylabel(“Energy (eV)”) plt.title(“H2O geometry optimization”); plt.tight_layout(); plt.show() We use the molecular UMA calculator to evaluate the energy, atomic forces, and atomization energy of a water molecule. We define isolated hydrogen and oxygen reference atoms with the correct spin multiplicities to construct the atomization-energy calculation. We then distort the water geometry, relax it with the LBFGS optimizer, and analyze the converged bond length, bond angle, and energy trajectory. Copy CodeCopiedUse a different Browser print(“n” + “=”*70) print(“SECTION 4: CH2 singlet-triplet gap (UMA is spin-aware!)”) print(“=”*70) singlet = molecule(“CH2_s1A1d”); singlet.info.update({“charge”: 0, “spin”: 1}) triplet = molecule(“CH2_s3B1d”); triplet.info.update({“charge”: 0, “spin”: 3}) singlet.calc = FAIRChemCalculator(predictor, task_name=”omol”) triplet.calc = FAIRChemCalculator(predictor, task_name=”omol”) gap = triplet.get_potential_energy() – singlet.get_potential_energy() print(f”E(triplet) – E(singlet) = {gap:.3f} eV ” f”(negative => triplet ground state; expt ~ -0.39 eV)”) print(“n” + “=”*70) print(“SECTION 5: Reaction energy of CH4 + 2 O2 -> CO2 + 2 H2O”) print(“=”*70) def relaxed_energy(name, spin=1): m = molecule(name) m.info.update({“charge”: 0, “spin”: spin}) m.calc = FAIRChemCalculator(predictor, task_name=”omol”) LBFGS(m, logfile=None).run(fmax=0.02, steps=200) return m.get_potential_energy() E = { “CH4”: relaxed_energy(“CH4”), “O2”: relaxed_energy(“O2”, spin=3), “CO2”: relaxed_energy(“CO2”), “H2O”: relaxed_energy(“H2O”), } dE_rxn = (E[“CO2”] + 2*E[“H2O”]) – (E[“CH4”] + 2*E[“O2″]) print(f”Delta E (electronic) = {dE_rxn:.2f} eV = {dE_rxn*96.485:.0f} kJ/mol”) print(“Experimental combustion enthalpy ~ -890 kJ/mol (ZPE/thermal not included here)”) from ase.vibrations import Vibrations print(“n” + “=”*70) print(“SECTION 6: Vibrational frequencies of relaxed H2O”) print(“=”*70) vib = Vibrations(h2o_bad, name=”vib_h2o”) vib.run() freqs = np.real(vib.get_frequencies()) real_modes = [f for f in freqs if f > 200] print(“Vibrational modes (cm^-1):”, “, “.join(f”{f:.0f}” for f in real_modes)) print(“Experimental H2O: 1595 (bend), 3657 (sym stretch), 3756 (asym stretch)”) print(f”Zero-point energy = {vib.get_zero_point_energy():.3f} eV”) vib.clean() We compare the singlet and triplet electronic states of methylene to calculate its spin-state energy gap. We relax methane, oxygen, carbon dioxide, and water before combining their predicted energies to estimate the electronic reaction energy of methane combustion. We also perform a finite-difference vibrational analysis of relaxed water to obtain its normal-mode frequencies and zero-point energy. Copy CodeCopiedUse a different Browser from ase.build import fcc100, add_adsorbate from ase.constraints import FixAtoms print(“n” + “=”*70) print(“SECTION 7: CO/Cu(100) relaxation + adsorption energy (oc20 task)”) print(“=”*70) slab = fcc100(“Cu”, size=(3, 3, 3), vacuum=8.0, periodic=True) slab.set_constraint(FixAtoms(mask=[a.tag > 1 for a in slab])) add_adsorbate(slab, molecule(“CO”), height=2.0, position=”bridge”) slab.calc = calc_cat opt = LBFGS(slab, logfile=None) opt.run(fmax=0.05, steps=300) E_slab_ads = slab.get_potential_energy() print(f”Relaxed CO/Cu(100) in {opt.get_number_of_steps()} steps, ” f”E = {E_slab_ads:.3f} eV”) clean = fcc100(“Cu”, size=(3, 3, 3), vacuum=8.0, periodic=True) clean.set_constraint(FixAtoms(mask=[a.tag > 1 for a in clean])) clean.calc = FAIRChemCalculator(predictor, task_name=”oc20″) LBFGS(clean, logfile=None).run(fmax=0.05, steps=300) E_clean = clean.get_potential_energy() co = molecule(“CO”); co.info.update({“charge”: 0, “spin”: 1}) co.calc = FAIRChemCalculator(predictor, task_name=”omol”) LBFGS(co, logfile=None).run(fmax=0.02, steps=100) E_co = co.get_potential_energy() E_ads = E_slab_ads – E_clean – E_co print(f”E(clean slab) = {E_clean:.3f} eV, E(CO gas) = {E_co:.3f} eV”) print(f”Adsorption energy (naive cycle) = {E_ads:.3f} eV”) print(“(oc20 uses its own DFT reference scheme; for publication-grade numbers”) print(” keep all species within a consistent task/reference framework.)”) We construct a periodic
